Passivation CQ Grade Galvanized Iron Coil BQB 420 Sheet Metal Coil

Product Categories
Wuxi Laiyuan Special Steel Co., Ltd.
Contact Now

Passivation CQ Grade Galvanized Iron Coil BQB 420 Sheet Metal Coil

Brand Name : TISCO BAOSTEEL

Model Number : Galvanized Coil

Certification : SGS BV

Place of Origin : China

MOQ : 1 ton

Price : To be negotiated

Payment Terms : L/C, T/T

Supply Ability : 8,000 ton per month

Delivery Time : 10-15 days after advance payment

Packaging Details : Kraft paper, wooden case, packaging according to customer requirements

Name : Galvanized steel coil GI coil iron steel products for Building material and Roofing sheet

Width : 600mm-1250mm,1250mm or under,600-1500mm

Standard : ASTM,AISI,GB,JIS,DIN

Length : as your requirements,Customer's Requirement

Application : roofing,Decor,Flange Plate,commercial use,Forming

Technique : Cold Rolled,Hot Rolled

Contact Now

Galvanized steel coil GI coil iron steel products for Building material and Roofing sheet

Galvanized Coil has excellent performance, possessing ideal comprehensive properties of corrosion resistance, formation and coating. It is produced by passing the steel sheet which has undergone the acid washing process and rolling process through the zinc pot, thereby applying zinc film to the surface. It has excellent corrosion resistance, paintability, and workability due to Zinc's characteristic.

Specification

Galvanized Coil
Thickness 0.12-4.0mm Tolerance +/-0.02mm
Width 30-1500mm Zinc Coating 30-275g/m2
Package weight

2 -6 ton per coil

 Surface

Passivation,Fat liquoring,

Stop-off lacquer
Hardness

HRB50-71(CQ Grade),

HRB45-55(DQ Grade)

 Tensile Strength

270-500(CQ Grade),

270-420(DQ Grade)
Yield Strength

140-300 (DQ Grade)

 Elongation Percentage 22 (CQ Grade thickness less 0.7mm),24 (DQ Grade thickness less 0.7mm)
Spangle coating Big Spangle, small Spangle,Spangle-free
Standard EN 10142,EN 10147,EN 10292,JIS G3302, ASTM A653/A653M, BQB 420
Grade DX51D+Z,DX52D+Z,DX53D+Z,DX54D+Z,S220GD+Z,DX51D+Z/SGCC/A653/Automotive grade,etc
Surface Treatment Passivation(C),Oiling(O),Lacquer sealing(L),Phosphating(P),Untreated(U)
Surface Structure Normal spangle coating (NS),minimized spangle coating(MS),spangle-free(FS)
Application

Building , Corrugated sheet Roofing, electrical, Appliances, Automobile industry,

Transport Packaging ,Machinery processing ,Interior decoration , Medical
Packing

Inside:Anti-rust paper,Plastic.

Outside:Steel inner and outside guard board,Circle Iron guard board for both side,Outside iron guard board, 3 Radial Strapping and 3 Latitude Strapping.

We can also pack according to your requirement.

Passivation CQ Grade Galvanized Iron Coil BQB 420 Sheet Metal Coil

Passivation CQ Grade Galvanized Iron Coil BQB 420 Sheet Metal Coil

Passivation CQ Grade Galvanized Iron Coil BQB 420 Sheet Metal Coil

Passivation CQ Grade Galvanized Iron Coil BQB 420 Sheet Metal Coil

FAQ

1. How is the quality of your products?
Our products are manufactured in strict accordance with national and international standards, and we test each product beforedelivery. If you would like to view our quality certification and various test reports, please ask us.
2. How about price?
We are a factory and be able to give you lowest price. Please trust the quotation we would give you, it is professional one.
3. Why should you chose us?
Chose happens because of quality, then price, We can give you both. Additionally, we can also offer professional products inquiry,products knowledge train(for agents), smooth goods delivery, excellent customer solution proposals.
